CareClear-PNP (PET/NYLON/PE) is a common lamination structure used in flexible packaging. it is the unique combination of three plastic films (the PET a short form of Polyethylene Terephthalate, Nylon also known as PA, and the PE a short form of Polyethylene) that gives our packaging film or bags its unique technical qualities making it ideally suited for a wide range of applications either for domestic or industrial use. The unique combination of PET, NYLON, AND PE enhances tear strength potential to reduce bag blowouts, specifically in powder and liquid packaging applications. This film also helps maintain freshness, extend shelf life and prevent damages to the contents of the package, in a non-rigid form.
This material has a higher than average moisture and strength, with good oxygen and gas barrier. As this is a clear product it has limited light barrier potential but does have good heat resistance. Enhanced heat resistance could be obtained with CareClear-PNC is required by the use application.
Note: The performance of any film will be influenced by a number of factors and testing must always be performed to ensure the film meets the use.
CarePac-PNP PET/NY/PE was a good candidate for this use case
Frozen Sea Moss is a widely consumed health and beauty supplement. Sea Moss is a plant product that is stored frozen and the then thawed by the consumer. CareClear-PNP was a good choice in this circumstance because the use case required a pouch with good liquid holding and freezer save material.
Nylon (PA) laminated in the PE/NYLON/PE film/bag is a very tough film with good transparency, good gloss, high tensile strength, good heat resistance, cold resistance, oil resistance. It is excellent in abrasion resistance, organic solvent resistance, and puncture resistance, and is relatively flexible, and has excellent oxygen barrier properties.
PET/NYLON/PE typically offers an excellent oxygen barrier and moderate moisture barrier. It's usually stiffer than other PET/PE films and has superior optical qualities. It exhibits high resistance to oil and acidic product contents, whereas PET/PE films are more likely to absorb and become distorted by those substances. PET/NYLON/PE chemical structure is very stable, which means it shows less stretching during the printing and laminating processes. It’s also revered for its excellent thermal stability.
The synthesizing of Nylon or PA material into PET/NYLON/PET FILM greatly impacts the oxygen and moisture barrier, makes for an opaque barrier to light, offers a high-reflective glossy aesthetic, and opens up new packaging application options unlike other PET/PE films or bags that are deficient in oxygen and moisture barrier as well as the glossy aesthetic. In terms of mechanical properties, such as modulus and tensile strength, PET/NYLON/PE typically outperforms PET/PE. At this time, PET/NYLON/PE is well suited for applications requiring a strong film with high tensile properties, scuff resistance, and durability.
The synthesizing of Nylon or PA material into PET/NYLON/PET FILM offers an improvement in the moisture barrier.
Here are some of the common indicated properties for PET/PA/PE:
2mil - 8mil
Sample Data Thickness
4 mil +/- 5μ
<30 JIS Z 0208
<5 JIS Z1707
>42.1 (MD), >42.1 (TD)
Elongation at Break
>55 (MD), >50 (TD) ASTM D 882
PET/NYLON >400, NYLON/PE >400 g/15mm
>1.6 (MD), >1.2 (TD) ASTM D 1938
>84.6 JAs St. (fed-std-101-2065)
Environmental Impact Of Our Bags
PET/NYLON/PE is theoretically recyclable, but the energy required to separate out the plastics from the lamination structure mean that, except for specific jurisdictions, PET/NYLON/PE often is not recycled. PET/NYLON/PE can be commercially recycled by thorough washing and re-melting, or by chemically breaking it down to its component materials to make new PET/NYLON/PE films or bags.
FDA Food Approved
EU Food Approved
RoHS / R.E.A.C.H
Common Uses of this Type of Packaging
Modified "Choose the Right Packaging Material for Your Product" section that uses smaller boxes and has just the icon and the industry name.
Component Details of PET/ Nylon/ PE Bags
POLYETHYLENE TEREPHTHALATE (PET)
Polyethylene Terephthalate (PET) or Polyester is a high-performance, crystal clear thermoplastic made from Ethylene Glycol and Dimethyl Terephthalate (DMT). PET is the ideal material for laminating films or bags for quality printing and lamination as well as good choice for high-performance plastic films and sheets. It has a relatively high melting point, which makes it the best choice for applications that demand high temperature sterilization.
Polyethylene or PE is known for its durability, lightweight thermoplastic with a varying crystalline structure. Polyethylene is used in applications ranging for films, tubes, plastic parts, laminates, and so on, in numerous packaging options including Beverages, Meat, Fresh Products, Baked Goods, Frozen Foods, For Industrial Packaging & Construction Materials, etc.
NYLON (POLYAMIDES, PA)
Nylon or Polyamides (PA) is a major high-performance engineering thermoplastics class because of its good balance of properties.
Nylon or PA is used because it is a substitute for low – strength metals in applications like automobile engines, and because of its high strength (relative to other plastics), high temperature resilience, and a high chemical compatibility.
This variation on the Nylon theme substitutes RCPP for the operative sealant layer. This substitution is a good use for various cases for example where extra heat resistance is desired.
When the the addition of Nylon / PA is not required a more economical choice is CareClear-PP a very common PET/PE laminated barrier film.
PVDC coated PET provided extra barrier for applications which need enhanced WVTR and OTR, with the greatest increase being for OTR barrier.
